10GbE M.2 B+M Key Ethernet Network Adapter, Single Port RJ45 LAN Card with AQC107 Chip for Industrial Control Servers - Perfect for High-Speed Data Transfer in Data Centers and Server Rooms

$56.29

$102.36

Safe 45%

10GbE M.2 B+M Key Ethernet Network Adapter, Single Port RJ45 LAN Card with AQC107 Chip for Industrial Control Servers - Perfect for High-Speed Data Transfer in Data Centers and Server Rooms

10GbE M.2 B+M Key Ethernet Network Adapter, Single Port RJ45 LAN Card with AQC107 Chip for Industrial Control Servers - Perfect for High-Speed Data Transfer in Data Centers and Server Rooms

$56.29

$102.36

45% Off

Delivery & Return: Free shipping on all orders over $50

Estimated Delivery: 10-15 days international

16 people viewing this product right now!

SKU: 84108154

Guranteed safe checkout

Description

huanzhi Supports large shipment offload, receiver scaling (RSS), direct cache access (), and headers Checksum improves network performance and reduces host CPU utilization Wake-on-LAN Power Management () Supports IPv4, IPv6 and IPv6/UDP checksum offload Supports extended frames (up to 16 kbytes) Quality of Service () Supports up to eight traffic classes and Data Center Bridging () Applicable network: 10GbR server NIC Main controller: Marvell AQC107 Bus type: M.2 B+M KEY Multimedia Interface: 1 x RJ45 Copper Cable Transmission rate: 10G/5G/2.5G/1000/100Mbps Network topology: 10GBASE-T / 5GBASE-T / 2.5GBASE-T / 1000BASE-T / 100BASE-T IEEE 802.3bz, IEEE 802.3, IEEE 802.3x, IEEE 1588, IEEE 802.3az -Energy Efficient Ethernet (EEE) Management functions: IPMI pass-through via SMBus or NC-SI, iSCSI boot, PXE remote boot, VLAN filtering Firmware Environment: Operating temperature: 0 - 55 Celsius (32 - 131 °F) Storage temperature: -40 - 70 Celsius (-40 - 158 Fahrenheit) Storage Humidity: 90% RH condensation at 35 Celsius Colour: Green Material: PCB Package includes: 1 x Network Card 1 x CD 1 x short iron piece. Only the above package, other products are not included. Note: light reflection and different screens may cause the colour of the item to be slightly different from the real thing. The allowed measurement error is +/- 1-3 cm.

Shipping & Returns

For all orders exceeding a value of 100USD shipping is offered for free.

Returns will be accepted for up to 10 days of Customer’s receipt or tracking number on unworn items. You, as a Customer, are obliged to inform us via email before you return the item.

Otherwise, standard shipping charges apply. Check out our delivery Terms & Conditions for more details.

Features

Integrated industrial grade M.2 B+M AQC107 10G network adapter, using the Marvell AQC107 high performance Ethernet controller.

The Marvell AQC107 controller has Base-T copper network interface, supports 10GBASE-T/5GBASE-T/2.5GBASE-T/1000BASE-T/100BASE-T and PCIe Gen3x4 or Gen2x4, AQtion Ethernet controller can easily handle 10GbE lines performance.

The AQC107 incorporates Aquantia's AQrate PHY technology to provide 10GbE network speeds over 6a and 5GbE and 2.5GbE network speeds over 100 meters of 5e or higher cable, allowing for higher data rates, no change to conventional cabling.

Designed for Any mobile device, desktop, workstation, industrial value server with strict space constraints. System Requirements Win 7/ Win 8/ Win 8.1/ Win 10/Server 2012/ Server 2016 32 or 64bits,Linux Kernels3.10 and higher, M.2 B+M KEY slot available.Compatible with PCIE Revision 3.0 and PCI Reivison2.0 downstream. Each line supports one of 8.0 GT/s and 5.0 GT/s line. Supports Gen3 x4 or Gen2 x4.

Support communication and management functions. Aquantia AQrate PHY integrated with NBASE-T technology. Supports PHY specification via 10GBASE-T /5GBASE-T /2.5GBASE-T /1000BASE-T /100BASE-T.High resolution cable analyzer on for advanced cable diagnostics.Support Energy Efficient Ethernet (EEE). Supports IEEE1588v2 precision time protocol.
